- 42 -GA-8GEM667K Motherboard
English
You must check whether your RAM&CPU support over clock when you set "Top Performance"
to " Enabled"
Top Performance
Top Performance
If you wish to maximize the performance of your system, set "Top Performance" as "Enabled".
!Disabled Disable this function. (Default Value)
!Enabled Enable Top Performance function.
Figure 9: Top Performance
CMOS Setup Utility-Copyright (C) 1984-2002 Award Software
!Standard CMOS Features Top Performance
!Advanced Chipset Features Load Fail-Safe Defaults
!Integrated Peripherals Load Optimized Defaults
!Power Management Setup Set Supervisor Password
!PnP/PCI Configurations Set User Password
!PC Health Status Save & Exit Setup
!Frequency/Voltage Control Exit Without Saving
ESC:Quit "#$%:Select Item
F8: Q-Flash F10:Save & Exit Setup
Top Performance
Disabled...................[ "]
Enabled...................[ ]
"#: Move ENTER: Accept
ESC: Abort
