Using The Test Tool
Using FlukeView® Software
1
41
Now you are ready to print.
To print a live screen, do the following:
Open the SAVE&PRINT menu.
Start printing.
To print a recalled screen, do the following:
Start printing.
A message that indicates that the test tool is printing
appears on bottom of the screen.
Using FlukeView
®
Software
To connect the test tool to a computer for using the
FlukeView software for Windows
®
(SW90W), do the
following:
Use the Optically Isolated RS-232 Adapter/Cable
(PM9080) to connect a computer to the OPTICAL
PORT of the test tool. See Figure 1-24.
For all information relating to installing and using the
FlukeView ScopeMeter software, see the SW90W Users
Manual.
A Software & Cable Carrying Case Kit is optional available
as model number SCC 120.
