Specifications
Miscellaneous
4
69
Miscellaneous
Display
Size ....................................72 x 72 mm (2.83 x 2.83 in)
Resolution ............................................240 x 240 pixels
Waveform Display:
Vertical .............................................8 div of 20 pixels
Horizontal ......................................9.6 div of 25 pixels
Backlight.................. Cold Cathode Fluorescent (CCFL)
Power
External: .............................via Power Adapter PM8907
Input Voltage .........................................10 to 21V DC
Power .........................................................5W typical
Input Connector.......................................... 5 mm jack
Fluke 123 (Internal Battery Pack BP120):
Battery Power.....................Rechargeable Ni-Cd 4.8V
Operating Time...............4 hours with bright backlight
4.25 hours with dimmed backlight
Charging Time.......................5 hours with test tool off
40 hours with test tool on
9 .. 14 hours with refresh cycle
Fluke 124 (Internal Battery Pack BP130):
Battery Power....................Rechargeable Ni-MH 4.8V
Operating Time...............6 hours with bright backlight
6.30 hours with dimmed backlight
Charging Time.......................7 hours with test tool off
60 hours with test tool on
12 .. 19 hours with refresh cycle
Allowable ambient temperature:
during charging ................. 0 to 45 °C (32 to 113 °F)
Memory
Number of Screen + Setup Memories (Fluke 123) .... 10
Number of Screen + Setup Memories (Fluke 124) .... 20
Mechanical
Size....................... 232 x 115 x 50 mm (9.1 x 4.5 x 2 in)
Weight ................................................... 1.2 kg (2.5 lbs)
including battery pack
Interface ..................................RS-232, optically isolated
To Printer..........................supports Epson FX, LQ, and
HP Deskjet
®
, Laserjet
®
, and Postscript
Serial via PM9080 (optically isolated RS-232
adapter/cable, optional).
Parallel via PAC91 (optically isolated print adapter
cable, optional).
To PC ....................... Dump and load settings and data
Serial via PM9080 (optically isolated RS-232
adapter/cable, optional), using SW90W (FlukeView
®
software for Windows
®
).
