Starting-up

• Start up / switch off the hob:

Action Control panel Display

To start press key [ ] 4 x [ 0 ] are blinking

To stop press key [ ] nothing or [ H ]

• Start up / switch off a heating zone:

Action Control panel Display

Zone selection press display [ 0 ] selected [ 0 ] and control light on

To set slide on the “SLIDER“ [ 0 ] to [ 9 ]

(adjust the power) to the right or to the left

To stop slide to [ 0 ] on “SLIDER“ [ 0 ] or [ H ]

or press on [ 0 ] [ 0 ] or [ H ]

If no action is made within 20 second the electronics returns in waiting position.

Pan detection

The pan detection ensures a perfect safety. The induction doesn’t work:

• If there is no pan on the heating zone or if this pan is not adapted to the induction. In this

case it is impossible to increase the power and the display shows [ U ]. This symbol

disappears when a pan is put on the heating zone.

• If the pan is removed from the heating zone the operation is stopped. The display shows

[ U ]. The symbol [ U ] disappears when the pan is put back to the heating zone. The

cooking continues with the power level set before.

After use, switch the heat element off: don’t let the pan detection [ U ] active.

Residual heat indication

After the switch off of a heating zone or the complete stop of the hob, the heating zones are still

hot and indicates [ H ] on the display.

The symbol [ H ] disappears when the heating zones may be touched without danger.

As far as the residual heat indicators are on light, don’t touch the heating zones and don’t put any

heat sensitive object on them. There are risks of burn and fire.

Booster function

The booster function [ P ] grants a boost of power to the selected heating zone.

If this function is activated the heating zones work during 10 minutes with an ultra high power.

The booster is foreseen for example to heat up rapidly big quantities of water, like nuddles

cooking.

• Start up / Stop the booster function:

Action Control panel Display Zone

Zone selection press key [ 0 ] from the zone [ 0 ] and control light on

Start up the booster press key [ P ] [ P ]

Stop the booster slide on the “SLIDER“ [ P ] to [ 0 ]

or press on [ P ] [ 9 ]
