1621
Users Manual
14
Troubleshooting
To troubleshoot your Tester, follow the steps in Table 4.
Table 4. Troubleshooting
Step Description
1 Auxiliary electrode resistance (RH) too high
If the auxiliary electrode resistance is too high (exceeds 199 ke), it
is not possible to drive the current necessary for reliable
measurements. The measurement is blocked and the >LIMIT icon
displays.
Hint: Verify that the auxiliary electrode stake is firmly embedded in
the soil, and ensure that good connections exist between all
connection points, like test leads, connectors and alligator clips.
2 Probe resistance (RS) too high
If the probe resistance is too high (exceeds 199 ke), it is not
possible to make an accurate measurement. The measurement is
blocked and the >LIMIT icon displays.
Hint: Verify that the probe stake is firmly embedded in the soil, and
ensure that good connections exist between all connection points,
like test leads, connectors and alligator clips.
3 Is your resistance measurement performed with the specified
operating uncertainty?
If the probe resistance (R
S
) or auxiliary electrode resistance (R
H
) is
too high to perform a measurement with the specified operating
uncertainty, the flashing W is displayed additionally to the
measurement values.
Hint: Verify that the probe stake and the auxiliary electrode are
firmly embedded in the soil and ensure that good connections exist
between all connection points, such as test leads, connectors and
alligator clips.
4 Is your resistance measurement result reliable?
To ensure the most reliable resistance measurements, the probe
stake and auxiliary electrode stake must be outside the potential
gradient area of each other and the earth ground electrode. (Refer
to the “Addendum” for information regarding potential gradient
areas.)
The probe should be a minimum distance of 20 m (64 ft) from the
earth ground electrode, and the auxiliary electrode should be a
minimum distance of 20 m (64 ft) from the probe.
For some soil conditions, these distances may not be sufficient. To
be sure, take several measurements, increasing the distance with
each subsequent measurement until the measurements are
approximately the same.
5 Weak battery
If the battery is weak (<6.5 V), the supply voltage may break down
during measurement. LO-BAT icon displays.
Hint: Replace the battery. Use one 9 V alkaline (LR61) battery.
