17
GB
air intake and exhaust vents must not be
closed. Please observe the information
provided by your sauna cabin supplier.
• For the adjustment and control of the sau-
na heating unit, one of the control units
mentioned later must be used. This con-
trol unit must be attached to a suitable lo-
cation on the outer wall of the cabin, the
associated sensor housings in the interior
of the sauna cabin in accordance with the
installation guide which accompanies the
control units.
• Caution: Covering and improperly
fi lled stone receptacles present a fi re
hazard.
• Make certain that no objects have
been placed on the sauna heating
unit before each start-up.
• Caution: High temperatures on the
heating unit during operation can
cause burns on contact.
• The sauna heating unit is not intended for
installation or placement in a niche under
the bench or under a roof slope.
• Do not start up operation of the sauna he-
ating unit with air intake vents closed.
• The cabin lighting with correspondi-
ng mounting must be of a type that it is
splash-proof and able to withstand a sur-
rounding temperature of 140° C. Therefo-
re, only a VDE-certifi ed sauna lamp of 40
W maximum may be installed for use with
the sauna oven.
• The sauna system (sauna heating
unit, control unit and lighting etc.)
may be hard-wired to the power sour-
ce only by a locally certifi ed electrician.
All connecting lines laid on the inside of
the cabin must be made of silicone and
be able to withstand a surrounding tem-
perature of at least 170°C. If single-wired
cables are used as connecting lines, they
must be protected by fl exible metal tubing.
The minimum diameter of the connecting
line and the suitable cabin size in proporti-
on to the power supply capacity are listed
Important notes
If assembled incorrectly, the sys-
tem will present a fi re hazard.
Please read this installation guide tho-
roughly. It is especially important to con-
sider applicable dimensions and observe
the following instructions:
• This device has not been designed for
being used by persons (including children)
that are physically or mentally handicap-
ped or have sensory disabilities. Moreover,
it is not allowed to use this device without
suffi cient experience and/or knowledge,
unless these persons will be supervised
by persons responsible for their security
or in case they have been instructed how
to use this device.
• Children are to be supervised in order to
make sure that they do not play with this
device.
• The installation and connection of the
sauna heating unit, control unit and
other electrical equipment must be ac-
complished only by an expert. In this re-
gard it is especially important to meet the
required safety precautions in accordance
with VDE 0100 v. §49 DA/6 and VDE 0100
part 703/2006-2.
• The sauna heating and control units may
be installed only in sauna cabins made of
suitable, low resin and untreated material
(for example: Nordic pine)
• Only a sauna oven with the appropriate
heating capacity may be installed in the
sauna cabin (see Table 2).
• There should always be a provision for air
intake and exhaust vents in every sauna
cabin. The air intake vents must always
be aligned behind the sauna heating unit,
ca. 5 to 10 cm above the fl oor. Please use
the minimum dimensions of the air intake
and exhaust vents listed in Table 1.
• The exhaust vents must always be placed
towards the sauna heating unit diagonally
in the rear sauna wall, lower area. The
