Ariens POWER BRUSH 28 [12/30] Filling fuel tank

Ariens POWER BRUSH 28 [12/30] Filling fuel tank

GB - 12

Install spacers on the wheel spindle above or

below the wheel support as shown. Turn the

spacers so the slot in the spacer does not

align with the flat sides on the wheel spindle.

Secure the spacers with the lock pin. (7).

NOTE: Set both wheels at the same height

for a level cut.

FILLING FUEL TANK

GASOLINE

IMPORTANT: ALWAYS use gasoline that

meets the following guidelines:

• Clean, fresh gasoline.

• A minimum of 87 octane/87 AKI (91

RON). High altitude use may require a

different octane. Consult your engine

manual.

• Gasoline with up to 10% ethanol

(gasohol) or up to 15% MTBE (methyl

tertiary butyl ether) is acceptable.

• Use of any gasoline other than those

approved above may void the engine

warranty. If the pumps are not marked

for the content of alcohol or ethers,

check ethanol and MTBE levels with

the fuel supplier.

• Do not modify the fuel system to use

different fuels.

• Never mix oil and gasoline.

NOTE: All gasoline is not the same. If the

engine experiences starting or performance

problems after using a new gasoline, switch

to a different fuel provider or fuel brand.

IMPORTANT: Excessively oxygenated or

reformulated fuels (fuels blended with

alcohols or ethers) can damage the fuel

system or cause performance problems. If

any undesirable operating problems occur,

use a gasoline with a lower percentage of

alcohol or ether.

Fuel Stabilizer

Gasoline left in the fuel system for extended

periods without a stabilizer will deteriorate,

resulting in gum deposits in the system.

These deposits can damage the carburetor

and the fuel hoses, filter and tank. Prevent

deposits from forming in the fuel system

during storage by adding a quality fuel

stabilizer to the fuel. Follow the

recommended mix ratio found on the fuel

stabilizer container.

To add fuel to the tank:

1. ALWAYS place unit in an open, well-

ventilated area.

2. Stop engine and allow to cool.

3. Clean fuel cap and surrounding area to

prevent dirt from entering the fuel tank.

4. Remove cap.

IMPORTANT: See engine manual for correct

type and grade of fuel to use.

5. Fill fuel tank to within 1/2 inch (1.27 cm)

below bottom of filler neck.

6. Replace fuel cap and tighten.

7. ALWAYS clean up any spilled fuel.

Figure 7

Align open end of the spacers with the

flat cut sides on the caster fork. Remove

the spacers from the bottom of the stack.

Secure spacers above the

caster arm with the lock pin.

OS6080

WARNING: FLAMMABLE FUEL

and its EXPLOSIVE VAPORS

can result in death or serious

injury. Handle fuel with extreme

care. ALWAYS use an approved

fuel container. NO Smoking! NO

Lighted Materials! No Open

Flames! Allow engine to cool

before any service.
