GB - 5
2. CAUTION!
• Engage traction drive clutch before
attachment clutch.
3. DANGER!
• Read the Owner’s Manual.
• Adjust brush height before operating.
• Engage traction drive clutch before
attachment clutch.
• Operating on irregular terrain could
cause the brush to dig in and drive the
machine rearward.
4. DANGER!
5. HOT SURFACES!
EMISSION CONTROL SYSTEM
This equipment and/or its engine may include
exhaust and evaporative emissions control
system components required to meet U.S.
Environmental Protection Agency (EPA)
and/or California Air Resources Board
(CARB) regulations. Tampering with
emission controls and components by
unauthorized personnel may result in severe
fines or penalties. Emission controls and
components can only be adjusted by an
Ariens Company dealer or an authorized
engine manufacturer's service center.
Contact your Ariens Company Equipment
Retailer concerning emission controls and
component questions.
SAFETY RULES
Read, understand, and follow all safety
practices in Owner/Operator Manual before
beginning assembly or operating. Failure to
follow instructions could result in personal
injury and/or damage to unit.
ALWAYS remove key and/or wire from spark
plug before assembly, maintenance or
service. Unintentional engine start up can
cause death or serious injury.
Complete a walk around inspection of unit
and work area to understand:
• Work area • Your unit • All safety decals
ALWAYS check overhead and side
clearances carefully before operation.
ALWAYS be aware of traffic when operating
along streets or curbs.
Keep children and people away. Keep
children out of work area and under watchful
care of a responsible adult.
NEVER allow children to operate or play on
or near unit. Be alert and shut off unit if
children enter area.
DO NOT allow adults to operate unit without
proper training.
Keep area of operation clear of all toys, pets,
and debris. Thrown objects can cause injury.
Check for weak spots on docks, ramps or
floors. Avoid uneven work areas and rough
terrain. Stay alert for hidden hazards.
Avoid uneven and rough terrain. DO NOT
operate near drop-offs, ditches, or
embankments. Unit can suddenly turn over if
a wheel is over the edge of a cliff or ditch, or if
an edge caves in.
Falling snow, fog, etc. can reduce vision and
cause an accident. Operate unit only when
there is good visibility and light.
Only trained adults may operate unit.
Training includes actual operation.
Keep people away from unit
while operating.
Never direct discharge towards
persons or property that may be
injured or damaged by thrown
objects.
Stop engine, remove key, read
manual before making any
repairs or adjustments.
ONLY use clean-out tool to clear
blockages. NEVER use your
hands.
Wear appropriate hearing
protection.
Avoid injury - Stay clear of
rotating parts.
DO NOT touch parts which are
hot from operation. ALWAYS
allow parts to cool.
OL4370
OL0910
OL4010
OL4690
OL1816
OL1801
