19
Menu Structure
Temperature Setup Menu
4 Menu Structure
Temperature Setup Menu4.1
4180/4181 MAIN MENU
F1 F2 F3 F4
TEMP SETUP PROG MENU SYSTEM MENU VIEW TEMP
F1 SCAN <change the scan rate and enable alarms>
SCAN RATE: <edit>
STABLE LIMIT: <edit>
STABLE ALARM: (ENABLE/DISABLE) <select>
F2 IRT <set display emissivity to match IR thermometer>
IRT İ: <edit>
F3 CUTOUT <modify hard and soft cutout>
SOFT CUTOUT: <edit>
HARD CUTOUT: <view only>
Hot Keys
SETPoinT Key - SET TEMPERATURE SETPOINT
SETPOINT: <set point temperature> <edit>
ENTER <enable control of the instrument>
F1 – SELECT PRESET <1-8> <select>
F1 – EDIT PRESET <1-8> <edit>
F4 – SAVE/DISABLE <disables control of the instrument>
ºC / ºF Key - Units: <°C, °F>
Up/ Down Arrow Keys <contrast adjust> <toggle>
Up Key: Lighter
Down Key: Darker
F1 & F4 Keys (same time)
<reset to English language>
F1 & F3 Keys (same time)
<turn off key press beep>
Figure 5 Temperature setup menu
