21
Menu Structure
System Menu
4.3 System Menu
4180/4181 MAIN MENU
F1 F2 F3 F4
TEMP SETUP PROG MENU SYSTEM VIEW TEMP
F1 SYSTEM SETUP
F1 DISPLaY SETUP
LANGUAGE: <ENGLISH, FRENCH, SPANISH, ITALIAN , GERMAN, RUSSIAN, JAPANESE, CHINESE ><select>
DECIMAL: <PERIOD, COMMA> <select>
KEY AUDIO: <OFF, ON> <select>
F2 COMM SETUP
BAUD RATE: <38400, 19200, 9600, 4800, 2400, 1200> <select>
LINEFEED: <ON, OFF> <select>
F2 PASSWORD
USER PASSWORD: <edit>
PROTECTION: <LOW, HIGH> <select>
F3 CALIBrate
F1 CONTRoL setup
TEMP ProportionalBAND: <edit>
TEMPerature INTegration:
<edit>
TEMPerature DERivative:
<edit>
F2 IR CALibration
IRCAL 1: <edit>
IRCAL 2:
<edit>
IRCAL 3:
<edit>
SURFACE: <edit>
WAVELENGTH: <8-14 um, USER> <select>
CALibration DATE: <edit>
F4 SYSTEM INFOrmation
MODEL: <view only>
SERIAL: <view only>
FW VERSION: <view only>
CALibration DATe: <view only>
Figure 7 System menu
