4180, 4181 Precision Infrared Calibrator
Program Menu
20
Program Menu4.2
4180/4181 MAIN MENU
F1 F2 F3 F4
TEMP SETUP PROG MENU SYSTEM MENU VIEW TEMP
F1 SELECT PROGram
PROGRAM: <1, … , 8> <select> Each program is represented by a unique number
NAME: <edit> Program name (may represent a thermometer model number)
F1 EDIT PROGram
PROGRAM: <view only>
NAME: <view only>
IRT İ: <edit> The emissivity setting of the thermometer to be calibrated
DISTANCE: <edit> <centimeters> Distance from thermometer to target during calibration
APERTURE: <YES, NO> <select> Yes indicates that an external aperture is required during calibration
STEPS: <1-8> <edit> The number of temperature set points used in the calibration program
SETPOINT 1: <edit>
SETPOINT 2: <edit>
SETPOINT 3: <edit>
SETPOINT 4: <edit>
SETPOINT 5: <edit>
SETPOINT 6: <edit>
SETPOINT 7: <edit>
SETPOINT 8: <edit>
F2 PROGram OPTION
SETTLE TEST: <AUTO, LIMIT> <select> Criteria for determining when the temperature of the target is stable
SOAK MINUTES: <edit> Length of time in minutes at which the calibrator remains at the set point temperature
ADVANCE: <PROMPT,AUTO> <select> Choice of advancing to the next step in the program automatically or prompted by user
CYCLES: <edit> Number of times the calibrator repeats the ramp/soak program
F3 RUN PROGram
PROGRAM: <view only> Each program is represented by a unique number
NAME: <view only> Program name (usually a thermometer model number)
STATUS: <RUN, OFF> <select> Run indicates that a program is in process and off indicates a program is not
Figure 6 Program menu
