Specifications | 8-7

USB Interface

Standard Based on Universal Serial Bus Specifications

Revision 1.0, Universal Serial Bus Device Class

Definition for Printing Devices Version 1.0

Bit rate 12 Mbps (full speed device)

Data encoding NRZI

Adaptable connector USB Series B

Recommended cable

length

6 feet (2 meters)
