Epson Stylus Pro 9000 [10/143] Using this
![Epson Stylus Pro 9000 [10/143] Using this](/views2/1053920/page10/bga.png)
3
Introduction | 3
Using This
Printer Guide
This guide contains the following information:
Chapter 1 gives instructions for loading roll paper and cut sheets, printing
on both EPSON and non-EPSON media, and using the paper hammock.
Chapter 2 explains how to monitor the printer’s status, respond to error
messages on the control panel, and configure printer settings.
Chapter 3 gives instructions for cleaning and aligning the print head,
replacing ink cartridges and the cutter blade, and cleaning and transporting
the printer.
Chapter 4 provides troubleshooting tips and solutions for problems
involving print quality, printer operation, and paper handling.
Chapter 5 provides the technical details on your printer, paper
requirements, and ink cartridges.
Appendix A gives instructions for installing an optional Ethernet interface
card.
Appendix B covers the installation and use of EPSON printer drivers and
utilities for Macintosh computers.
Appendix C covers the installation and use of EPSON printer drivers and
utilities for Windows computers.
An IIndex is included at the end of the book.
