2-2
2-2 | Monitoring and Configuring the Printer
Monitoring Normal Printer Operation
Messages appear on the control panel display and lights come on or flash to
indicate various phases of printer operation. The following table explains the
status messages and lights:
Pausing and Resetting the Printer
If you need to stop the printer during a print job, press the
Pause
button.
Press the
Pause
button again to resume printing.
If you decide to cancel a job after the printer has started processing it, you
can reset the printer. Press the
Pause
button and hold it down for 3 seconds.
This clears all data in the printer’s memory.
Checking Printer Status
You can use the control panel to print a status check or nozzle check. These
prints allow you to test the printer without sending a print job (and without
connecting the printer to the RIP). You can also check the amount of ink
remaining, total number of prints, and the status of your cutter blade and
other printer parts.
Status messages
Message
Light Explanation or response
READY Operate
light on Printer is ready to print.
PRINTING Operate
light flashing Printer is receiving data.
INK DRY FOR
<number> MIN
Pause
light flashing Printer is paused between
passes to let ink dry. Wait for the
number of minutes shown.
RESET
All lights flash briefly Printer is resetting.
PRESS PAUSE
BUTTON
Pause
light on Press the
Pause
button to
continue.
WAIT Pause
light on or
flashing
Printer is warming up, performing
maintenance, or charging ink.
PAUSE Pause
light on Printer is paused. To resume
printing, press the
Pause
button.
