5-5
Specifications | 5-5
Safety Approvals
Ink Cartridges
Print capacity may vary, depending on how often you run print head
cleaning cycles and how much you use the printer. Capacity of the initial
cartridge set is reduced because of ink charging.
Safety standards UL 1950, CSA 22.2 No. 950
EMC FCC part 15 subpart B class B, CSA C108.8 class B
Print capacity Approx. 28 pages/A0 (720 dpi, 40% duty)
Approx. 6,400 pages/A4 (360 dpi, 5% duty)
Cartridge life 2 years from production date if unopened;
within 2 years after opening package, at 77 °F
(25 °C)
Temperature
Storage (uninstalled) –22 to 104 °F (–30 to 40 °C) 1 month at 104 °F
Storage (installed) –4 to 104 °F (–20 to 40 °C) 1 month at 104 °F
Transit –22 to 140 °F (–30 to 60 °C)
1 month at 104 °F, 120 hours at 140 °F
Freezing 5 °F (–15 °C); ink thaws and is usable after at
least 3 hours at 77°F (25 °C)
Dimensions
Width 0.99 in. (25.1 mm)
Depth 10.24 in. (260.0 mm)
Height 4.15 in. (105.3 mm)
Weight Approximately 0.82 to 0.85 lb (370 to 385 g)
Capacity 7.4 oz (220 ml)
