Инструкция по эксплуатации Страница: 143

Epson Stylus Pro 9000 [143/143] Printer parts back

optional interface

shield plate

AC inlet

parallel interface

connector

serial interface

connector

ink cartridge

compartment

ink cartridge

compartment
