B-8
B-8 | Using EPSON Drivers and Utilities for Macintosh
6. If you’re using Photoshop
®
5.0.2, you’ll see settings for
Space
and
Printer Color Management
in your dialog box. See your Photoshop
documentation for instructions on using these settings.
7. Choose from the following buttons to access additional features:
•
Click to access the printer monitoring and maintenance utilities.
See page B-18 for more information.
•
Click if you want to reduce your image to fit on the page.
•
Click to turn on background printing. This lets you use the
Monitor3 utility. See page B-12 for more information.
•
Click and then click the
Preview
button to see a preview of
your printed image.
8. When you’re finished choosing print options, click
Print.
Custom print job settings
Setting Usage
Advanced
Prevents the misprinting of ink dots that may occur
because of the movement of the print head and
paper. Available only when you choose photo or
photo-quality media types.
PhotoEnhance3
Produces sharper images and more vivid colors by
automatically adjusting the contrast, saturation,
and brightness. Corrects for overall under- or
over-exposure of the original image
Digital Camera
Corrects noise and other flaws common in digital
camera images.
Text/Graph
Intensifies colors and lightens the midtones and
highlights. Best for print jobs with
non-photographic images.
ColorSync
®
Adjusts colors based on your printer’s ICC profile,
using the perceptual rendering intent.
Note
You can also create your
own settings and add
them to this list. See
page B-10 for more
information.
