Ebara COMPACT A/8 [10/13] Bearings

MULTISTAGE CENTRIFUGAL PUMPS COMPACT

CONSTRUCTION 50Hz

302

EBARA Pumps Europe S.p.A.

Rev. J

BEARINGS

Single Phase Three Phase [1~] [3~] [1~] [3~]

COMPACT AM/4 COMPACT A/4 6201 2RSH 6201 2RSH 6201 2RSH 6201 2RSH

COMPACT AM/6 COMPACT A/6 6201 2RSH 6201 2RSH 6201 2RSH 6201 2RSH

COMPACT AM/8 COMPACT A/8 6201 2RSH 6201 2RSH 6201 2RSH 6201 2RSH

COMPACT AM/10 COMPACT A/10 6203 2RSH 6203-ZZ C3 6202 2RSH 6202-ZZ C3

COMPACT AM/12 COMPACT A/12 6203 2RSH 6203-ZZ C3 6202 2RSH 6202-ZZ C3

COMPACT AM/15 COMPACT A/15 6203 2RSH 6203-ZZ C3 6202 2RSH 6202-ZZ C3

COMPACT BM/12 COMPACT B/12 6203 2RSH 6203-ZZ C3 6202 2RSH 6202-ZZ C3

COMPACT BM/15 COMPACT B/15 6203 2RSH 6203-ZZ C3 6202 2RSH 6202-ZZ C3

Pump side Fan side

Type pumps

QUANTITY FOR MODEL

PUMP

N° 7

Impeller

N° 9

Diffuser

N° 62

Stage housing

COMPACT A/4 2 1 1

COMPACT A/6 3 2 2

COMPACT A/8 4 3 3

COMPACT A/10 5 4 4

COMPACT A/12 6 5 5

COMPACT A/15 7 6 6

COMPACT B/12 4 3 3

COMPACT B/15 5 4 4
