MULTISTAGE CENTRIFUGAL PUMPS COMPACT
DIMENSIONS AND WEIGHT 50Hz
401
EBARA Pumps Europe S.p.A.
Rev. J
PACKING
[1~] [3~]
COMPACT AM/4 COMPACT A/4 185 195 375 8.9 8.9
COMPACT AM/6 COMPACT A/6 185 195 375 9.8 9.8
COMPACT AM/8 COMPACT A/8 185 195 375 10.8 10.8
COMPACT AM/10 COMPACT A/10 212 201 515 15.5 15.5
COMPACT AM/12 COMPACT A/12 212 201 515 16.6 17.3
COMPACT AM/15 COMPACT A/15 212 201 515 17.7 17.9
COMPACT BM/12 COMPACT B/12 212 201 515 15.9 16.7
COMPACT BM/15 COMPACT B/15 212 201 515 16.9 16.9
Weight
[kgf]
ZYThree PhaseSingle Phase
Type pumps Packing [mm]
X
[1∼] Single phase
[3∼] Three phase
