MULTISTAGE CENTRIFUGAL PUMPS COMPACT
SPECIFICATION 50Hz
200
EBARA Pumps Europe S.p.A.
Rev. J
PUMP
Liquid
Handled
Type of liquid Clean water
Temperature [°C]
min. +5
max. +40
Maximum working pressure [MPa] 1
Construction
Impeller Closed centrifugal
Shaft seal type Mechanical seal
Bearing Sealed ball bearing
Pipe
Connection
Suction
G 1” (Compact A version) UNI ISO 228
G 1”¼ (Compact B version) UNI ISO 228
Discharge G 1” (All version) UNI ISO 228
Material
Casing Cast iron
Impeller PPE+PS Glass Fiber Reinforced
Shaft seal Ceramic/Carbon/NBR
External pump casing AISI 304
Shaft AISI 416
Stages PPE+PS Glass Fiber Reinforced/PTFE
Diffuser PPE+PS Glass Fiber Reinforced
Bracket Cast iron
Applicable standard of test ISO 9906:2012 – Grade 3B
MOTOR
Type
Electric - TEFC
Single Phase Three Phase
Efficiency level (Reg. 640/2009) -
- from 0.3 kW up to 0.6 kW
IE3 from 0.75 kW up to 1.1 kW
No. of Poles 2
Rotation speed [min
-1
]
≈ 2800
Insulation Class F
Protection degree (CEI EN 60034-5) IP 44
Power rating
[kW] 0.3 ÷ 1.1
[HP] 0.4 ÷ 1.5
Frequency [Hz] 50
Voltage [V] 230 ±10% 230/400 ±10%
Capacitor Built in -
Over load protection Built in Provided by the user
Casing material Aluminium
Base material/motor support Cast iron
Dimensions of cable entry PG11 - M16x1.5
