CMI C-B-BH-87/55 [23/56] Check before starting the device
23
– Retighten the safety lever(25).
Coupling handle
►P.3, item1
When the coupling handle is released, the
cable pull must be completely relaxed; When
the coupling handle is pulled, the cable pull
must be tensioned in such a way that the
spring on the coupling handle starts to
extend.
– Coupling handle pulled (position []) =
Chopping tool turns;
– Coupling handle released (position [])
= Unit is running in idle.
Chopping spur
►P.4, item4
The forwards movement of the unit is braked
by the chopping spur. The required chopping
depth is achieved by digging the spur into
the ground at different depths.
(►Mounting the chopping spur– p.22)
Front support wheel
►P.5, item6
The front support wheel makes it easier to
push the unit. When chopping, it must be
folded upwards.
– Pull the front support wheel from the
fixed position.
– Fold the front support wheel upwards
and click into place.
Filling with fuel
►P.3, item2
– Unscrew the tank lid(7) and remove.
– Carefully pour fuel into the tank (max.
1600ml). Do not spill!
– Check the seal in the tank lid for dam-
ages, and clean if necessary. Immedi-
ately replace damaged seals!
– Tighten the tank lid(7) by hand.
Filling with motor oil
►P.3, item2
– Unscrew the motor oil filling screw(12)
and remove.
– Fill with motor oil carefully. Do not spill!
– Tighten the motor oil filling screw(12) up
again by hand.
Operation
Check before starting the device!
Check to make sure the device is in safe
operating condition:
– Check that no leaks have developed.
DANGER!
Risk of injury!
Petrol is extremely flammable!
– Switch off the motor and allow to
cool down before refilling.
– Observe all of the safety notes for
handling fuels.
NOTICE!
Risk of damage to the device!
The unit is delivered without motor
oil.
Motor oil must be filled before start-
ing the machine.
STOP
Note:
Only use suitable fuels (►Fuel and
lubricants to be used– p.28).
NOTICE!
Risk of damage to the device!
The unit is delivered without motor
oil.
Motor oil must be filled before start-
ing the machine.
Operating the motor with insufficient
oil will damage the motor.
Direct oil and oil designed for two-
stroke motors will shorten the lifetime
of the motor.
Use the prescribed motor oil (►Fuel
and lubricants to be used– p.28).
DANGER!
Risk of injury!
The device may only be put into
operation if there are no defects. If a
part is defective, it must be replaced
before the device is used again.
GB
