12
TASCAM DR-100MKIII
2 – Names and functions of parts
Menu list
Press the MENU button to open the MENU screen.
The menu items are as follows.
Menu item Function Page
BROWSE
Work with files and folders on the SD card see page 32
REC SETTING
FORMAT
Set the recording file format
see page 21
SAMPLE
Setting the sampling frequency
FILE TYPE
Set the file type see page 21
XRI
Turn XRI data recording on/off see page 28
DUAL REC
Set dual recording function see page 27
FILE INC
Set the recording time interval for automatically dividing (creating
new) files
see page 27
AUTO REC
Set the auto-recording function see page 25
PRE REC
Set the pre-recording function see page 26
AUTO TONE
Set the auto tone function see page 28
I/O SETTING
SOURCE
Set the input source see page 21
A/D FILTER
Set the A/D converter filter see page 24
DUAL ADC
Turn on/off this function that improves S/N performance see page 25
LOW CUT
Set the low-cut filter see page 23
LEVEL CONTROL
Set the level control function see page 23
MS DECODE
Set the mid-side decoding function see page 24
PHANTOM VOLT
Set the phantom power voltage see page 22
PLUG IN POWER
Turn plug-in power on/off see page 22
OUTPUT ATT
Set the output attenuator function see page 44
MARK SETTING
AUTO MARK
Set the automatic mark function see page 38
PEAK MARK
Turn the peak mark function on/off see page 39
MARK SKIP
Set the mark skip mode see page 39
POWER/DISPLAY
AUTO PWR SAVE
Set the automatic power saving function see page 40
BATTERY
Makes settings related to the built-in and replaceable batteries see page 40
BACKLIGHT
Set the time the backlight stays lit see page 40
BRIGHTNESS
Set the backlight brightness see page 40
CONTRAST
Adjust the contrast see page 40
INDICATORS
Turn indicators on/off see page 40
PEAK LEVEL
Set the level meter peak hold function see page 41
SYSTEM
INFORMATION
Shows a variety of information. see page 41
DATE/TIME
Set the date and time see page 17
FILE NAME
Set the file name format. see page 36
FILE No.RESET
Reset the file number. see page 37
REMOTE
Make connected remote control settings see page 46
LANGUAGE
Set the language shown on the display see page 16
INITIALIZE
Restore factory default settings see page 43
MEDIA FORMAT
Format the SD card see page 43
USB STORAGE
Switch to USB mass storage device mode see page 45
CAUTION
•
When recording or in recording standby, the MENU screen will not open.
•
The settings for all menu items are retained even when the unit is turned off (in standby).
