Hotpoint-Ariston ARTXL 129 [2/48] Installation

Installation

 Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction

manual accompanies the washing machine to inform

the new owner as to its operation and features.

 Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking and levelling

Unpacking

1. Unpack the

washing machine.

2. Check whether the

washing machine has

been damaged during

transport. If this is the

case, do not install it

and contact your

retailer.

3. Remove the four

protective screws and

the rubber washer

with the respective

spacer, situated on

the rear of the

appliance (see figure).

4. Seal the gaps using the plastic plugs provided.

5. Keep all the parts: you will need them again if

the washing machine needs to be moved to

another location.

Warning: should the screws be re-used, make sure

you fasten the shorter ones at the top.

 Packaging materials are not children's toys.

Levelling

Your machine may make a considerable amount of

noise if the two front feet have not been adjusted

correctly.

1. Install the washing

machine on a flat

sturdy floor, without

resting it up against

walls, furniture cabinets

or other.

2. If the floor is not

perfectly level, com-

pensate for any

unevenness by

tightening or loosening

the adjustable front feet (see figure); the angle of

inclination, measured according to the worktop,

must not exceed 2°.

Levelling your appliance correctly will provide it with

stability and avoid any vibrations, noise and shifting

during operation. If it is placed on a fitted or loose

carpet, adjust the feet in such a way as to allow

enough room for ventilation beneath the washing

machine.

Putting your appliance in place and moving it.

If your washing

machine is equipped

with a special set of

retractable wheels you

can easy move it. To

lower the wheels and

thus move the

appliance effortlessly,

just pull the lever,

situated on the left-

hand side beneath the

base. Once the

appliance is in the required position, put the lever

back in place. The washing machine is now firmly in

place (see figure).

Electric and water connections

Connecting the water inlet hose

1. Insert seal A into the

end of the inlet hose and

screw the latter onto a

cold water tap with a 3/4

gas threaded mouth (see

figure).

Before making the

connection, allow the

water to run freely until it

is perfectly clear.

2. Connect the other

end of the water inlet

hose to the washing

machine, screwing it

onto the appliance's

cold water inlet, situated

on the top right-hand

side on the rear of the

appliance (see figure).

3. Make sure there are no kinks or bends in the hose.

 The water pressure at the tap must be within the

values indicated in the Technical details table

(on the next page).

 If the water inlet hose is not long enough, contact

a specialist store or an authorised serviceman.
