Hotpoint-Ariston ARTXL 129 [5/48] Il hotpoint

Function buttons and corresponding indicator lights

When a function is selected, the corresponding

indicator light will illuminate.

If the selected function is not compatible with the

programmed wash cycle, the corresponding indicator

light will flash and the function will not be activated.

If a function which is incompatible with another

function selected previously, only the most recent

selection will remain active.

Lid locked indicator light

If this indicator light is on, the appliance door is locked to

prevent it from being opened accidentally; to avoid any

damage, wait for the indicator light to switch off (it will take

about three minutes) before you open the appliance door.

N.B. If the DELAY TIMER function is activated, the door

cannot be opened; pause the machine by pressing the

START/PAUSE button if you wish to open it.

 If the START/PAUSE indicator light (orange) flashes

rapidly at the same time as the function indicator

light, this indicates a problem has occurred (see

Troubleshooting).

How to open and to close the drum

Wash

Rinse

Spin

Drain

End of wash cycle

Fig. 1

Fig. 2

Fig. 3

Fig. 4

A) Opening (Fig. 1):

Lift the external lid and open it completely.

B) Opening the drum (Soft opening):

With one finger, push the button indicated in fig. 2

and the drum will open delicately.

C) Loading the washing machine (Fig. 3).

D) Shutting (Fig. 4):

- close the drum fully by first shutting the front

door followed by the rear one;

- then ensure the hooks on the front door are

perfectly housed within the seat of the rear door;

- after the hooks have clicked into position, press

both doors lightly downwards to make sure they

do not come loose;

- finally shut the external lid.

Starting a wash cycle

1. Switch the washing machine on by pressing the

ON/OFF button. All indicator lights will switch on for a

few seconds, then they will switch off and the START/

PAUSE indicator light will pulse.

2. Load the laundry, close the door and the lid.

3. Set the WASH CYCLE knob to the desired

programme.

4. Set the washing temperature (see

Personalisation).

5. Set the spin speed (see Personalisation).

6. Measure out the detergent and washing additives

(see Detergents and laundry).

7. Select the desired functions.

8. Start the wash cycle by pressing the START/

PAUSE button and the corresponding indicator light

will remain lit in a fixed manner, in green.

To cancel the set wash cycle, pause the machine by

pressing the START/PAUSE button and select a new

cycle.

9. At the end of the wash cycle the

indicator light

will switch on. The LID LOCKED indicator light will

switch off, indicating that the door may be opened.

Take out your laundry and leave the appliance door

ajar to make sure the drum dries completely.

Switch the washing machine off by pressing the ON/

OFF button.
