Hotpoint-Ariston ARTXL 129 [3/48] H hotpoint

Technical data

Model

ARTXL 129

Dimensions

width 40 cm

height 85 cm

depth 60 cm

Capacity

from 1 to 6 kg

Electrical

connections

please refer to the technical data

plate fixed to the machine

Water connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 42 litres

Spin speed

up to 1200 rotations per minute

Energy rated

programmes

according to

regulation

EN 60456

programme 7; temperature 60°C;

using a load of 6 kg.

This appliance conforms to the

following EC Directives:

- 89/336/EEC dated 03/05/89

(Electromagnetic Compatibility) and

subsequent modifications

- 2002/96/EC

- 2006/95/EC (Low Voltage)

Connecting the drain hose

Connect the drain hose,

without bending it, to a

drainage duct or a wall

drain located at a height

between 65 and 100 cm

from the floor;

alternatively, rest it on

the side of a washbasin

or bathtub, fastening the

duct supplied to the tap

(see figure). The free end

of the hose should not

be underwater.

 We advise against the use of hose extensions; if it is

absolutely necessary, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

 the socket is earthed and complies with all

applicable laws;

 the socket is able to withstand the maximum power

load of the appliance as indicated in the Technical

data table (see opposite);

 the power supply voltage falls within the values

indicated in the Technical data table (see opposite);

 the socket is compatible with the plug of the

washing machine. If this is not the case, replace

the socket or the plug.

 The washing machine must not be installed

outdoors, even in covered areas. It is extremely

dangerous to leave the appliance exposed to rain,

storms and other weather conditions.

 When the washing machine has been installed, the

electricity socket must be within easy reach.

 Do not use extension cords or multiple sockets.

 The cable should not be bent or compressed.

 The power supply cable must only be replaced by

authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and before

you use it for the first time, run a wash cycle with

detergent and no laundry, using the wash cycle 2.

65 - 100 cm
