Parameter listing and descriptions 203
ACH550-01 User's Manual
35 = COMM – Energise the relay based on the input from the fieldbus
communication.
• Fieldbus writes a binary code in parameter 0134 that energises
relay 1…relay 6 according to the table below.
• 0 = De-energise the relay, 1 = Energise the relay.
36 =
COMM(-1) – Energise the relay based on the input from the fieldbus
communication.
• Fieldbus writes a binary code in parameter 0134 that energises
relay 1…relay 6 according to the table below.
• 0 = De-energise the relay, 1 = Energise the relay.
37 =
TIMER 1 – Energise the relay when timer 1 is activated.
• See Group 36: TIMED FUNCTIONS.
38…40 =
TIMER 2…4 – Energise the relay when timer 2…4 is active.
• See
TIMER 1 above.
41 =
MNT TRIG FAN – Energise the relay when the cooling fan counter is
triggered.
42 =
MNT TRIG REV – Energise the relay when the revolutions counter is
triggered.
43 = MNT TRIG RUN – Energise the relay when the run time counter is
triggered.
44 =
MNT TRIG MWH – Energise the relay when the power consumption
counter is triggered.
45 = OVERRIDE – Energise the relay when override is activated.
46 =
START DELAY – Energise relay when a start delay is active.
47 =
USER LOAD C – Energise the relay when a user load curve fault or
alarm occurs.
Code Description Range
Par. 0134 Binary RO6 RO5 RO4 RO3 RO2 RO1
0 0000000 00000
1 0000010 00001
2 0000100 00010
3 0000110 00011
4 0001000 00100
5…62 … … ……………
63 111111 1 11111
Par. 0134 Binary RO6 RO5 RO4 RO3 RO2 RO1
0 000000 1 1 1 1 1 1
1 000001 1 1 1 1 1 0
2 000010 1 1 1 1 0 1
3 0000111 11100
4 000100 1 1 1 0 1 1
5…62 … … ……………
63 111111 0 0 0 0 0 0
