Technical data 419
ACH550-01 User's Manual
Air flow, 380…480 V drives
The following table lists the requirements for the cooling air flow
data for 380…480 V drives at full load in all ambient conditions
listed in Ambient conditions on page 440.
Drive Heat dissipation Air flow Noise
ACH550-01- Frame size W BTU/hr m
3
/h ft
3
/min dB
02A4-4 R1 30 101 44 26 52
03A3-4 R1 40 137 44 26 52
04A1-4 R1 52 178 44 26 52
05A4-4 R1 73 249 44 26 52
06A9-4 R1 97 331 44 26 52
08A8-4 R1 127 434 44 26 52
012A-4 R1 172 587 44 26 52
015A-4 R2 232 792 88 52 66
023A-4 R2 337 1151 88 52 66
031A-4 R3 457 1561 134 79 67
038A-4 R3 562 1919 134 79 67
045A-4 R3 667 2278 134 79 67
059A-4 R4 907 3098 280 165 75
072A-4 R4 1120 3825 280 165 75
087A-4 R4 1440 4918 280 165 75
125A-4 R5 1940 6625 350 205 75
157A-4 R6 2310 7889 405 238 77
180A-4 R6 2810 9597 405 238 77
195A-4 R6 3050 10416 405 238 77
246A-4 R6 3260 11133 405 238 77
290A-4 R6 3850 13125 405 238 77
00467918.xls C
