164 Serial communications
ACH550-02 User's Manual
Fault handling
The ACH550 indicates all faults in clear text and fault number in
the control panel (operator keypad) display. Refer to chapter
Diagnostics and maintenance. Additionally, a fault code is
allocated to each fault name shown in parameters 0401, 0412
and 0413. The fieldbus-specific fault code is indicated as a
hexadecimal value coded according to the DRIVECOM
specification. Note that not all fieldbuses support the fault code
indication. The table below defines the fault codes for each fault
name.
Fault name in control panel Drive
fault code
Fieldbus fault code
OVERCURRENT 1 2310h
DC OVERVOLT 2 3210h
DEV OVERTEMP 3 4210h
SHORT CIRC 4 2340h
DC UNDERVOLT 6 3220h
AI1 LOSS 7 8110h
AI2 LOSS 8 8110h
MOT OVERTEMP 9 4310h
PANEL LOSS 10 5300h
ID RUN FAIL 11 FF84h
MOTOR STALL 12 7121h
EXT FAULT 1 14 9000h
EXT FAULT 2 15 9001h
EARTH FAULT 16 2330h
Obsolete 17 FF6Ah
THERM FAIL 18 5210h
OPEX LINK 19 7500h
OPEX PWR 20 5414h
CURR MEAS 21 2211h
SUPPLY PHASE 22 3130h
OVERSPEED 24 7310h
DRIVE ID 26 5400h
CONFIG FILE 27 630Fh
SERIAL 1 ERR 28 7510h
