Installing the drive 47
ACH550-02 User’s Manual
Preparing the mounting location
On concrete floor
Bare (concrete) floor where cables come through openings
made on the floor below the drive. The floor or floor material of
the installation place must not be flammable.
1. Lift the drive against the wall into the mounting place.
2. Mark the locations of the two wall fixing points.
3. Mark the bottom edges of the drive to the floor.
On a cable channel
In this case there are various ways how to fix the drive onto the
channel.
1. Check that there is a place for the fixing holes.
2. Check that there is space under the lead-through plate for
the cables.
On a raised floor
This method is used in cases when several drives are located in
the same space close to each other. The raised floor is normally
constructed on-site.
1. Check that there is a place for the fixing holes.
2. Check that the route is free for the main cables.
Against a wall
The drive is not designed to be wall mounted, but it is
recommended that drive should be fastened to the wall for extra
stability and support.
1. Lift the drive against the wall into the mounting place.
2. Check that the cable openings through the floor are in an
appropriate position.
3. Mark the bottom edges of the drive to the floor.
4. Mark the locations of the two wall fixing points.
