Parameter listing and descriptions 169
ACH550-02 User's Manual
• Group 64: LOAD ANALYZER - Defines the load analyzer for
analyzing the customer’s process and sizing the drive and
the motor
• Group 81: PFA CONTROL – Defines pump and fan
alternation mode of operation.
• Group 98: OPTIONS – Configures options for drive.
