11
• Do not use any cleaning agents or solvents, since they may
damage plastic parts.
• The tool should be cleaned with a dry piece of cloth, brush or
blown with compressed air of low pressure.
• Venting slots in the motor housing should be cleaned on a regular
basis not to overload the tool.
• When the commutator sparks excessively, have the condition of
motor carbon brushes checked by a qualified person.
• The tool should be always stored in a dry place and out of reach
of children.
REPLACING THE WORKING DISC
A worn or damaged working disk should be immediately
replaced.
• Loosen and unscrew the disc clamping bolts and eye shield
(Fig. K).
• Remove both shields (Fig. L).
• Insert the spindle lock pin into the housing hole (Fig. M).
• Loosen and unscrew the clamping bolt of the working disc (5)
(Fig. N).
• Replace the working disc with a new one and fasten it by
tightening the bolt (Fig. O).
REPLACING THE CARBON BRUSHES
Worn (shorter than 5 mm), burnt or cracked motor carbon
brushes should be immediately replaced. Both carbon brushes
should be always replaced at the same time.
Carbon brushes should be replaced by a qualified person using
original spare parts only.
All types of faults and defects should be eliminated by an authorised
service of the manufacturer.
SPECIFICATIONS
RATED DATA
Chain Sharpener
Parameter Value
Power supply voltage 230 V AC
Power supply frequency 50 Hz
Rated power 180 W
Idle speed: 6300 min
-1
Disc diameter 100 mm
Inner disc diameter 10.2 mm
Disc width 3.2 mm
Sharpening angle range 35°
Protection class II
Weight 2.1 kg
Year of manufacturer 2017
NOISE AND VIBRATION DATA
Acoustic pressure level Lp
A
= 82.7 dB(A) K = 3 dB(A)
Acoustic power level Lw
A
= 95.7 dB(A) K = 3 dB(A)
Vibration acceleration weighted value a
h
= 3,2 1 m/s
2
K = 1,5 m/s
2
ENVIRONMENT PROTECTION
Do not dispose of electrically powered products with household
wastes, they should be utilized in proper plants. Obtain information
on wastes utilization from your seller or local authorities. Used up
electric and electronic equipment contains substances active in
natural environment. Unrecycled equipment constitutes a potential
risk for environment and human health.
* Right to introduce changes is reserved.
“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka komandytowa
with seat in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs,
that all copyrights to this instruction (hereinafter Instruction), including, but not
limited to, text, photographies, schemes, drawings and layout of the instruction,
belong to Grupa Topex exclusively and are protected by laws accordingly to
Copyright and Related Rights Act of 4 February 2004 (ustawa o prawie autorskim
i prawach pokrewnych, Dz. U. 2006 No 90 item 631 with later ammendments).
Copying, processing, publishing, modifications for commercial purposes of the
entire Instruction or its parts without written permission of Grupa Topex are
strictly forbidden and may cause civil and legal liability.
