Samsung HDC6C55UX [29/84] English

- 29 -

GENERAL

Carefully read the following important information regarding

installation safety and maintenance. Keep this information

booklet accessible for further consultations. The appliance

has been designed for use in the ducting version (air exhaust

to the outside - Fig.1B), ltering version (air circulation on

the inside - Fig.1A).

SAFETY PRECAUTION

Take care when the cooker hood is operating simultane-

ously with an open replace or burner that depend on the air

in the environment and are supplied by other than electrical

energy, as the cooker hood removes the air from the environ-

ment which a burner or replace need for combustion. The

negative pressure in the environment must not exceed 4Pa

(4x10-5 bar). Provide adequate ventilation in the environment

for a safe operation of the cooker hood. Follow the local laws

applicable for external air evacuation.

Before connecting the model to the electricity network:

- Control the data plate (positioned inside the appliance)

to ascertain that the voltage and power correspond to the

network and the socket is suitable. If in doubt ask a qualied

electrician.

- If the power supply cable is damaged, it must be replaced

with another cable or a special assembly, which may be

obtained direct from the manufacturer or from the Technical

Assistance Centre.

- This device must be connected to the supply network

through eiter a plug fused 3A or hardwired to a 2 fase spur

protected by 3A fuse.

Warning!

In certain circumstances electrical appliances may be a

danger hazard.

A) Do not check the status of the filters while the cooker

hood is operating.

B) Do not touch bulbs or adjacent areas, during or straight

after prolonged use of the lighting installation.

C) Flambè cooking is prohibited underneath the cooker

hood.

D) Avoid free flame, as it is damaging for the filters and a

fire hazard.

E) Constantly check food frying to avoid that the over-

heated oil may become a fire hazard.

F) Disconnect the electrical plug prior to any maintenance.

G) This appliance is not intended for use by young children

or infirm persons without supervision.

H) Young children should be supervised to ensure they do

not play with the appliance.

I) There shall be adequate ventilation of the room when

the rangehood is used at the same time as appliances

burning gas or other fuels.

L) There is a risk of fire if cleaning is not carried out in

accordance with the instructions.

This appliance conforms to the European Directive EC/2002/96,

Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner, the

user is helping to prevent potential damage to the environ-

ment or to public health.

The symbol on the product or on the accompanying

paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to

a suitable electric and electronic appliance recycling collection

point. Follow local guidelines when disposing of waste. For

more information on the treatment, re-use and recycling of

this product, please contact your local authority, domestic

waste collection service or the shop where the appliance was

purchased.

INSTALLATION INSTRUCTIONS

Assembly and electrical connections must be carried out

by specialised personnel.

•ElectricConnection:

The appliance has been manufactured as a class II, therefore

no earth cable is necessary.

The connection to the mains is carried out as follows:

BROWN = L line

BLUE = N neutral

If not provided, connect a plug for the electrical load indicated

on the description label. Where a plug is provided, the cooker

hood must be installed in order that the plug is easily acces-

sible. An omnipolar switch with a minimum opening of 3mm

between contacts, in line with the electrical load and local

standards, must be placed between the appliance and the net-

work in the case of direct connection to the electrical network.

• The minimum distance between the support surfaces of

the cooking pots on the cooker top and the lowest part of

the cooker hood must be at least 65 cm. If a connection tube

composed of two parts is used, the upper part must be placed

outside the lower part. Do not connect the cooker hood ex-

haust to the same conductor used to circulate hot air or for

evacuating fumes from other appliances generated by other

than an electrical source.

Before proceeding with the assembly operations, remove the

anti-grease lter(s) (Fig.7) so that the unit is easier to handle.

- In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

•  We recommend the use of an air exhaust tube which has

the same diameter as the air exhaust outlet hole. If a pipe

with a smaller diameter is used, the eciency of the product

may be reduced and its operation may become noisier.

•Fixingtothewall:

Drill the holes A respecting the distances indicated (Fig.2). Fix

the appliance to the wall and align it in horizontal position

to the wall units. When the appliance has been adjusted,

denitely x the hood using the screws A (Fig.5). For the vari-

ous installations use screws and screw anchors suited to the

type of wall (e.g. reinforced concrete, plasterboard, etc.). If

the screws and screw anchors are provided with the product,

check that they are suitable for the type of wall on which the

hood is to be xed.

•Fixingthedecorativetelescopicue:

Take care not to scratch the duct; wear gloves when removing

the protective lm (Fig.3).

Arrange the electrical power supply within the dimensions of

ENGLISH
