8
www.emotron.com
Operation at higher temperatures
Emotron AC drives are designed for nominal operation at maximum of 40°C ambient temperature.
However, for most models, it is possible to use the AC drive at higher temperatures with reduced output rating (derating).
Possible derating
Derating of output current is possible with
-1% / degree Celsius to max +10 °C (max 50 °C for IP2Y)
-1% / degree Celsius to max +15 °C (max 55 °C for IP54 and IP20/21)
-0.55% / degree Fahrenheit to max +18 °F (max 122 °F for IP2Y)
-0.55% / degree Fahrenheit to max +27 °F ( max 131 °F for IP54 and IP20/21)
Dimensions, weights and cooling air ow
The tables below give an overview of the dimensions, weights, and the required air flow for cabinet mounting of the modules.
Drives with model numbers up to 48-293 are available as wall mounted modules; with the choice of an IP54 version (frame size B to F), and an
IP20/21 version (frame size C2 to F2) that is also optimized for cabinet mounting.
Market Standard Description
European
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
WEEE Directive 2002/96/EC
All
EN 60204-1
Safety of machinery - Electrical equipment of machines
Part 1: General requirements.
EN(IEC)61800-3:2004
Adjustable speed electrical power drive systems
Part 3: EMC requirements and specific test methods.
EMC Directive: Declaration of Conformity and CE marking
EN(IEC)61800-5-1 Ed. 2.0
Adjustable speed electrical power drive systems Part 5-1.
Safety requirements - Electrical, thermal and energy.
Low Voltage Directive: Declaration of Conformity and CE marking
IEC 60721-3-3
Classification of environmental conditions. Air quality chemical vapours, unit in
operation. Chemical gases 3C2, Solid particles 3S2.
Optional with coated boards
Unit in operation. Chemical gases Class 3C3, Solid particles 3S2.
UL508C UL Safety standard for Power Conversion Equipment
North & South America
USL
USL (United States Standards - Listed) complying with the requirements of UL508C
Power Conversion Equipment
UL 840
UL Safety standard for Power Conversion Equipment.
Insulation coordination including clearances and creepage distances for
electrical equipment.
CNL
CNL (Canadian National Standards - Listed) complying with the requirements of
CAN/CSA C22.2 No. 14-10 Industrial Control Equipment.
Russian EAC For all sizes. (Former GOST R)
