English
13
Ventilation
Ventilation illustration
Air inlet
Air inlet
Air outlet
Exhaust vent requirements
For proper ventilation of the projector, make sure to leave some space around the projector as
shown in the illustration below:
11.8 in / 30 cm
or greater
11.8 in / 30 cm
or greater
R/Pr G/Y B/Pb
HDBaseT / LAN
3D Sync Out
RGB IN
RS-232 USBTRIGGER
HV
Display Port
DVI-D
WIRE
RGB OUT
HDMI
MENU EXIT
POWER
INPUT
AUTO
SYNC ASPECT
FOCUS
LENS
SHIFT
ZOOM
SHUTTER
CENTER
LENS
19.7 in / 50 cm
or greater
19.7 in / 50 cm
or greater
