English
3
Product information
Packing contents
Carefully unpack and verify that you have the items below. Some of the items may not be available
depending on your region of purchase. Please check with your place of purchase.
Projector
without lens
Warranty card
Quick start guide
Anti-Theft screw Lens hole cap
Power cable VGA cable
Wired remote cable
User manual CD
MENU
EXIT
ENTER
1
4
7
0
89
6
3
5
2
Remote
without AA batteries
