English
6
Installation
Lens specifications
Model
Name
Lens Type
BenQ Part
Number
Optical spec Throw Ratio Zoom Ratio Weight*
LS1ST4
Ultra Short
Throw
5J.JCY37.002 F=2.0, f=5.64 mm 0.38:1 Fixed 2,710g
LS1ST3 Wide fix 5J.JAM37.011 F=1.85, f=11.6mm 0.76:1 Fixed 910g
LS1ST2 Ultra Wide 5J.JAM37.061
F=1.96~2.3,
f=11.3~14.1mm
0.75~0.93:1 1.25:1 1,280g
LS1ST1 Wide Zoom 5J.JAM37.021
F=1.85~2.5,
f=18.7~26.5mm
1.25~1.79:1 1.41:1 1,090g
LS1SD Standard 5J.JAM37.001
F=1.7~1.9,
f=26~34mm
1.73~2.27:1 1.3:1 820g
LS1LT1 Semi Long 5J.JAM37.051
F=1.86~2.48,
f=32.9~54.2mm
2.22~3.67:1 1.65:1 950g
LS1LT2 Long Zoom1 5J.JAM37.031
F=1.85~2.41,
f=52.8~79.1mm
3.58~5.38:1 1.5:1 1,020g
LS1LT3 Long Zoom2 5J.JAM37.041
F=1.85~2.48,
f=78.5~121.9mm
5.31~8.26:1 1.55:1 1,350g
Note:
The values listed in the table above are average and may vary by model.
