Safety
2 24 690 32 Rev. CKohlerEngines.com
SAFETY PRECAUTIONS
WARNING: A hazard that could result in death, serious injury, or substantial property damage.
CAUTION: A hazard that could result in minor personal injury or property damage.
NOTE: is used to notify people of important installation, operation, or maintenance information.
WARNING
Explosive Fuel can
cause fi res and severe
burns.
If a gaseous odor is
detected, ventilate
area and contact an
authorized service
technician.
Propane is extremely fl ammable
and is heavier than air and tends
to settle in low areas where a
spark or fl ame could ignite gas.
Do not start or operate this engine
in a poorly ventilated area where
leaking gas could accumulate and
endanger safety of persons in
area.
To ensure personal safety,
installation and repair of propane
fuel supply systems must be
performed only by qualifi ed
propane system technicians.
Improperly installed and
maintained propane equipment
could cause fuel supply system or
other components to malfunction,
causing gas leaks.
Observe federal, state and local
laws governing propane fuel,
storage, and systems.
WARNING
Rotating Parts can cause
severe injury.
Stay away while engine
is in operation.
Keep hands, feet, hair, and
clothing away from all moving
parts to prevent injury. Never
operate engine with covers,
shrouds, or guards removed.
CAUTION
Failure to utilize or
reassemble debris
screen as designed could
result in debris screen
failure and serious
personal injury.
WARNING
Carbon Monoxide can
cause severe nausea,
fainting or death.
Avoid inhaling exhaust
fumes. Never run engine
indoors or in enclosed
spaces.
Engine exhaust gases contain
poisonous carbon monoxide.
Carbon monoxide is odorless,
colorless, and can cause death if
inhaled.
WARNING
Accidental Starts can
cause severe injury or
death.
Disconnect and ground
spark plug lead(s) before
servicing.
Before working on engine or
equipment, disable engine as
follows: 1) Disconnect spark plug
lead(s). 2) Disconnect negative (–)
battery cable from battery.
WARNING
Hot Parts can cause
severe burns.
Do not touch engine
while operating or just
after stopping.
Never operate engine with heat
shields or guards removed.
WARNING
Cleaning Solvents can
cause severe injury or
death.
Use only in well
ventilated areas away
from ignition sources.
Carburetor cleaners and solvents
are extremely fl ammable. Follow
cleaner manufacturer’s warnings
and instructions on its proper and
safe use. Never use gasoline as a
cleaning agent.
CAUTION
Electrical Shock can
cause injury.
Do not touch wires while
engine is running.
CAUTION
Damaging Crankshaft
and Flywheel can cause
personal injury.
Using improper procedures can
lead to broken fragments. Broken
fragments could be thrown from
engine. Always observe and use
precautions and procedures when
installing fl ywheel.
WARNING
High Pressure Fluids can
puncture skin and cause
severe injury or death.
Do not work on fuel
system without proper
training or safety
equipment.
Fluid puncture injuries are highly
toxic and hazardous. If an injury
occurs, seek immediate medical
attention.
