Propane EFI System

Fault Codes

Example of Diagnostic Display

One second pause

Three second pause

(0)

(7)

(6)

(1)

End Code 61

Fault

Code

0107

Diagnostic Fault Code Summary

Fault Code Connection or Failure Description

0031 Oxygen Sensor Heater Circuit Low Voltage

0032 Oxygen Sensor Heater Circuit High Voltage

0107 Manifold Absolute Pressure (MAP or TMAP) Sensor Circuit Low Voltage or Open

0108 Manifold Absolute Pressure (MAP or TMAP) Sensor Circuit High Voltage

0112 Intake Air Temperature (IAT or TMAP) Sensor Circuit Low Voltage

0113 Intake Air Temperature (IAT or TMAP) Sensor Circuit High Voltage or Open

0117 Coolant/Oil Temperature Sensor Circuit Low Voltage

0118 Coolant/Oil Temperature Sensor Circuit High Voltage or Open

0122 Throttle Position Sensor Circuit Low Voltage or Open

0123 Throttle Position Sensor Circuit High Voltage

0131 Oxygen Sensor 1 Circuit Low Voltage, or Open

0132 Oxygen Sensor 1 Circuit High Voltage

0171 Maximum Adaptation Limit Exceeded

0172 Minimum Adaptation Limit Exceeded

0174 Lean Fuel Condition at High Load (Open Loop)

0201 Injector 1 Circuit Malfunction

0202 Injector 2 Circuit Malfunction

0230 Fuel Lock-Oﬀ Circuit Low Voltage or Open

0232 Fuel Lock-Oﬀ Circuit High Voltage

0336 Crankshaft Position Sensor Noisy Signal

0337 Crankshaft Position Sensor No Signal

0351 Cylinder 1 Ignition Coil Malfunction

0352 Cylinder 2 Ignition Coil Malfunction

0562 System Voltage Low

0563 System Voltage High

61 End of Code Transmission
