Specifi cations
6 24 690 32 Rev. CKohlerEngines.com
Engine Dimensions with Low-Profi le Air Cleaner
Dimensions in millimeters.
Inch equivalents shown in [ ].
FLYWHEEL SIDE
299.14
[11.777]
413.75
[16.289]
59.90 [2.358]
AIR CLEANER
COVER REMOVAL
OIL FILL
VALVE COVER
VALVE COVER
AIR CLEANER COVER
72.41
[2.851]
SPARK PLUG
REMOVAL
72.87
[2.869]
SPARK PLUG
REMOVAL
319.23
[12.568]
SPARK PLUG
REMOVAL
320.88
[12.633]
SPARK
PLUG
BOOT
REMOVAL
18.53
[0.729]
OIL FILTER
REMOVAL
20˚
20˚
29.24
[1.151]
SPARK PLUG
BOOT
473.01
[18.622]
319.12
[12.564]
SPARK PLUG
REMOVAL
320.68
[12.625]
SPARK
PLUG
BOOT
REMOVAL
CRANKSHAFT
ENGINE MOUNTING SURFACE
ENGINE
MOUNTING HOLE “A”
134.80
[5.307]
139.99
[5.512]
184.20
[7.252]
92.10
[3.626]
4X Ø 10.8 [0.425] MOUNTING HOLES (THRU)
70.21
[2.764]
SPARK
PLUG
BOOT
REMOVAL
71.29
[2.807]
SPARK PLUG
BOOT
REMOVAL
29.47
[1.160]
SPARK PLUG
BOOT
444.
6
[17.5
0
LIFT STRAP
STARTER SIDE
ENGINE MOUNTING SURFACE
MOUNTING HOLE “A”
89.00
[3.504]
51.00
[2.008]
12.26
[0.483]
OIL DRAIN PLUG 3/8 NPT [INCH]
50.00 [1.969]
SPARK PLUG
REGULATOR RECTIFIER
ENGINE MOUNTING SURFACE
OIL FILTER SIDE
DIPSTICK
OIL FILL
64.02
[2.520]
155.58
[6.125]
4.04
[0.159]
PILOT
152.08
[5.987]
OIL FILTER
52.75 [2.077]
OIL FILTER
99.96
[3.939]
89.00
[3.504]
MOUNTING HOLE “A”
51.00
[2.008]
15.07
[0.593]
12.26
[0.483]
OIL DRAIN PLUG 3/8” NPT
Ø 36.25 [1.427]
95.50
[3.760]
113.15
[4.455]
X Ø 47.5-50.0
5/8-18 UNF-2B INCH 38.1
CTSK Ø 19.0-21.0 X 60˚
115.90
[4.563]
353.02
[13.898]
69.02
[2.717]
30.00 [1.181]
SPARK PLUG
PTO SIDE
REGULATOR ASSEMBLY
ENGINE MOUNTING SURFACE
308.12
[12.131]
334.79
[13.181]
75.29
[2.964]
SOLENOID SHIFT STARTER
MOUNTING HOLE “A”
LIFT STRAP
PILOT Ø 146.05
[5.750]
4 X Ø 21.0
5/16-24 UNF-2B INCH 17.0
CTSK Ø 7.0 X 90˚
4 X Ø 25.0
3/8-16 UNC-2B INCH 21.0
CTSK Ø 12.0 X 90˚
4 X Ø 25.0
7/16-14 UNF-2B INCH 21.0
CTSK Ø 13.5 X 90˚
