OPERATION

CONTROLLING TEMPERATURES

The refrigerator controls its temperature automatically. However, if needed, adjust the temperature as follows.

Freezer

compartment

• If the refrigerator is operated for a long time with

FREEZER TEMP. CONTROL set at 7(MAX),

foods stored in the refrigerator compartment may

also freeze.

Refrigerator

compartment

• If the refrigerator is operated for a long time with REFRIGERA-

T OR TEMP. CONTROL set at 7 (MAX), foods stored in the refrig-

erator compartment may also freeze.

• Low ambient temperature may cause placed foods to freeze even

if REFRIGERATOR TEMP. CONTROL is set to 1 (MIN).

HINTS WHEN MAKING ICE

1. Do not over fill the Ice cube trays; otherwise the

ice cubes will be joined together when frozen.

NOTE:

To prevent damage to the Ice cube box,

do not make ice in the Ice cube box or

pour oil into it.

Lever

Ice cube box

2. When the ice cubes are made, turn

the lever clockwise to empty the ice

into Ice cube box.

7(MAX)

4(MED)

1(MIN)

For making ice rapidly or fast

freezing.

When frozen food or ice cream is

not stored.

For normal freezing.

7(MAX)

4(MED)

1(MIN)

For keeping foods fresher tasting.

When the refrigerator does not provide sufficient

cooling.

For normal operation.

When the refrigerator provides excessive cooling.

MIN

MED

MAX

Coldest

REFRIGERATOR TEMP. CONTROL

FREEZER TEMP. CONTROL

MIN

MAX

MED

Coldest

INSTALLATION

NOTE:

• Keep your refrigerator out of direct sunlight.

• Position your refrigerator so that the plug is accessible.

• Do not place next to heat generating appliance.

• Do not place directly on the ground. Provide suitable stand.

When transporting

Carry the refrigerator by holding

Using the casters, it is possible

to move back and forth.

the handles located on the rear

and bottom.

Before using your refrigerator

Clean the inside parts with a cloth

soaked in warm water. If soapy wa-

ter is used, wipe it off thoroughly.

Adjustable

foot

Evaporating

pan cover

Using the two front Adjustable feet, en-

sure that the refrigerator is positioned

firmly and level on the floor.

Clip Evaporating pan cover (supplied in-

side the refrigerator compartment) in po-

sition in front of the two Adjustable feet.

Casters

•

Keep adequate ventilation space around the

refrigerator.

•

The figure shows the minimum required space for

installing the refrigerator. It differs from the space in

the measurement condition of the amount of power

consumption.

•

It is possible to use the refrigerator with a less amount

of power consumption by keeping greater space.

•

If using the refrigerator in the space below dimension

of the figure, it may cause the temperatures in the unit

to rise, loud noise, and failure.

60 mm

or more

60 mm

or more

90 mm or more

1350 mm

1480 mm
