Indesit WD 84 T [13/80] The washer dryer doesn t dry properly

Too much foam.

Is the detergent appropriate

for machine washing? Check

whether the definition on its

label reads “for machine wash”

or “hand and machine wash”,

or any other similar wording.

Is the correct amount being

used? An excessive amount of

detergent, besides producing

too much foam, does not

guarantee a more effective

wash, and causes scaling in the

internal parts of the appliance.

The washer-dryer does

not dry.



Check whether:

the plug has been correctly

inserted into the socket; there

is electricity in your home; the

appliance door has been shut

properly; a delayed start (if

available) has not been

selected; programme knob A

has been set to position

(Stop/Reset); the drying cycle

knob C has been set to

position 0.

The washer-dryer doesn't

dry properly.



Check whether:

the end of the drain hose is

underwater; the drain pump is

obstructed; the advice given

on the maximum loads has

been taken; the water tap has

been turned on.

If, despite all checks, the washer-

dryer fails to function and the

problem persists, call your

nearest authorised Customer

Service Centre, providing the

following information:

- the nature of malfunction

- the model type no. (Mod. ....)

- the serial number (S/N ....)

This information can be found on

the data plate situated at the back

of the washer-dryer.

Is there space between the

machine and adjacent

units? If it is not a built-in

model, the washer-dryer will

oscillate a bit during the spin

cycle. A few cm of space

should therefore be left

around it.

The washer-dryer leaks.

Is the metal ring of the inlet

hose properly attached?

Turn off the water supply,

unplug the appliance and try

tightening its attachment

without forcing it.

Is the detergent dispenser

obstructed? Remove and

wash it under tap water.

Is the drain hose well

attached? Turn off the water

supply, unplug the appliance

and try tightening its

attachment.

Is the drain hose kinked?

The tract of the drain hose

must be as straight as

possible. Make sure the drain

hose is not squashed or

kinked.

Is the washer-dryer’s drain

duct clogged? Is there an

extension of the drain hose?

If so, is it positioned

incorrectly, blocking the

water flow?

Excessive vibration

during the spin cycle.

Have all transit screws been

removed durind instal-

lation? See the following

page on installation

procedures.

Has the washer-dryer been

levelled correctly? The

levelling of the appliance

should be checked

periodically. Adjust the feet

and check them with a level.

The washer-dryer does

not drain or spin.

Does the selected

programme incorporates

water draining? Some

programmes stop at the end

of the wash cycles and

draining will have to be

selected manually.

Is the “Anti-crease"

function -where provided -

enabled? This function

requires manual selection for

draining.

Is the drain pump clogged?

To check it, turn off the water

supply, unplug the washer-

dryer and follow the

instructions on page 12, or

call for technical assistance.

Technical characteristics

Always get

assistance from

authorised

technicians and

always insist on

original spare parts.

Instructions for installation and use

Model

WD 84 T

Dimensions

width 59,5 cm

height 85 cm

depth 53,5 cm

Capacity

from 1 to 5 kg for the wash programme; from 1 to 3,5 kg for the drying programme

Electrical

connections

voltage 220/230 Volt 50 Hz

maximum absorbed power 1850 W

Water connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0,05 MPa (0,5 bar)

drum capacity 46 litre

Spinning speed

up to 800 rpm

Control programs

in compliance with

IEC regulation 456

wash: programme 3; temperature 60°C; carried out with 5 kg load.

drying: run with a load of 2.5 kg and knob C et to position .

This appliance conforms with the following E.E.C. directives:

- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications

- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and subsequent

modifications
