maintenance manager, approved dealer, etc . . .).
• That the warnings and instructions marked on the
machine are followed (adequate personal
protection, correct use, general safety
instructions, etc).
• That no modification, transformation or addition is
detrimental to safety and that it is carried out
without prior authorization from the manufacturer.
• Respect of the maintenance intervals and
periodical checks recommended.
• That only genuine spare parts are used for
repairs.
Instruction plate
FAILURE TO COMPLY WITH THESE
WARNINGS COULD RESULT IN
DEATH OR SERIOUS BODILY INJURY.
DO
DO carefully read and understand all the
instructions before operating the saw.
DO always keep all guards in place.
DO aways wear safety approved hearing, eye,
head and respiratory protection.
DO keep all parts of your body away from the blade
and all other moving parts.
DO know how to stop the saw quickly in case of an
emergency.
DO shut off the engine and allow it to cool before
refueling.
DO inspect the blade, flanges and shafts for
damage before installing the blade.
DO use only blades marked with a maximum
operating speed greater than the blade shaft
speed.
DO use caution and follow the instructions when
loading and unloading the saw.
DO NOT
DO NOT allow other persons to be near the saw when
starting, refueling or when cutting.
DO NOT operate gasoline engines in an enclosed area
unless it is properly vented.
DO NOT use damaged equipment or blades.
DO NOT operate the saw in areas of combustible
material. Sparks from the saw could cause a
fire or an explosion.
DO NOT allow blade exposure from the guard to be
over 180 degrees.
DO NOT leave the saw unattended with the motor
running.
DO NOT operate the saw while under the influence of
drugs or alcohol.
1 - USE
• Use : wet sawing new and old concrete and
asphal
• Tools : Diamond Blades - water cooled Ø 350
mm or 400 mm or 450 mm - bore 25.4 mm
(Information from your usual supplier).
3 – DESCRIPTION OF THE MACHINE
01 - Handle
02 - Lowering wheel
03 - Graduated scale
hsilgnE - 2/6
