ENGLISH (Original instructions)
5
Using an extension cable
♦ Always use an approved extension cable suitable for
the power input of this tool (see technical data). Before
use, inspect the extension cable for signs of damage,
wear and ageing. Replace the extension cable if
damaged or defective. When using a cable reel, always
unwind the cable completely. Use of an extension cable
not suitable for the power input of the tool or which is
damaged or defective may result in a risk of fire and
electric shock.
Features
This tool includes some or all of the following features.
1. Variable speed switch
2. Lock-on button
3. Forward/reverse button
4. Drilling mode selector
5. Chuck
6. Depth stop
7. Side handle
Assembly.
Warning! Before assembly, make sure that the
tool is switched off and unplugged.
Fitting the side handle and depth stop (fig.A,B)
♦ Turn the grip counter clockwise until you can slide
the side handle (7) onto the front of the tool as shown
(fig.A).
♦ Rotate the side handle into the desired position.
♦ Insert the depth stop(6) into the mounting hole as
shown (fig.B).
♦ Set the drilling depth as described below.
♦ Tighten the side handle by turning the grip clockwise.
Fitting a drill bit (fig.C)
♦ Open the chuck by turning the sleeve (5) counter
clockwise.
♦ Insert the bit shaft (9) into the chuck (drill bit not
included).
♦ Insert the chuck key(10) into each hole (8) in the side of
the chuck and turn clockwise until it is tight.
Removing and refitting the chuck (fig.D)
♦ Open the chuck as far as possible.
♦ Remove the chuck retaining screw, located in the
chuck, by turning it clockwise using a screwdriver.
♦ Tighten an Allen key into the chuck and strike it with a
Impact as shown.
♦ Remove the Allen key. Remove the chuck by turning it
counter clockwise.
♦ To refit the chuck, screw it onto the spindle and secure
it with the chuck retaining screw.
Use
Warning! Let the tool work at its own pace.Do not
overload.
Warning! Before drilling into walls, floors or
ceilings, check for the location of wiring and pipes.
Selecting the direction of rotation (fig.E)
For drilling and for tightening screws, use forward
(clockwise) rotation For loosening screws or removing a
jammed drill bit, use reverse (counter clockwise) rotation.
♦ To select forward rotation, push the forward/reverse
button (3) to the left position.
♦ To select reverse rotation, push the forward/reverse
button (3) to the right. Warning! Never change the
direction of rotation while the motor is running.
Selecting the drilling mode
♦ For drilling in masonry, set the drilling mode selector (4)
to the position.
♦ For drilling in other materials and for screwdriving, set
the drilling mode selector to the position.
Setting the drilling depth (fig.B)
♦ Slacken the side handle (7) by turning the grip counter
clockwise.
♦ Set the depth stop(6) to the desired position. The
maximum drilling depth is equal to the distance
between the tip of the drill bit and the front end of the
depth stop.
♦ Tighten the side handle by turning the grip clockwise.
Switching on and off
♦ To switch the tool on, press the variable speed
switch(1). The tool speed depends on how far you press
the switch. As a general rule, use low speeds for large
diameter drill bits and high speeds for smaller diameter
drill bits.
♦ For continuous operation, press the lock-on button (2)
and release the variable speed switch. This option is
available only at full speed in both forward and reverse
modes.
♦ To switch the tllo off, release the variable speed switch.
To switch the tool off when in continuous operation,
press the variable speed switch again and release it.
♦ Based on the different applications, turn around the
speed dial(11) to control the maximum speed.
Drilling in metal
Start drilling with slow speed and increase to full power
while applying firm pressure on the tool. A smooth even
flow of metal chips indicates the proper drilling rate. Use a
cutting lubricant when drilling metals. The exceptions are
cast iron and brass which should be drilled dry.
