AXIS COMMUNICATIONS
<Product Name> Quick User’s Guide
About this Document
This manual is intended for administrators and users of the AXIS 214 PTZ PTZ
Network Camera, and is applicable for software release 4.49. Previous
experience of networking will be of use when installing and using this
product. Some knowledge of UNIX or Linux-based systems may also be
beneficial, for developing shell scripts and applications. Later versions of this
document will be posted to the Axis Website, as required.
Safety Notices Used In This Manual
Caution! - Indicates a potential hazard that can damage the product.
Important! - Indicates a hazard that can seriously impair operation.
Do not proceed beyond any of the above notices until you have fully
understood the implications.
Intellectual Property Rights
Axis AB has intellectual property rights relating to technology embodied in
the product described in this document. In particular, and without limitation,
these intellectual property rights may include one or more of the patents listed
at http://www.axis.com/patent.htm and one or more additional patents or
pending patent applications in the US and other countries.
This product contains licen
sed third-party software. See the menu item
“About” in the product’s user interface for more information.
This product contains source code copyright
Apple Computer, Inc., under the
terms of Apple Public Source License 2.0 (see
http://www.opensource.apple.com/apsl/).
The source code is available from:
http://developer.apple.com/darwin/projects/bonjour/
Legal Considerations
Video surveillance can be prohibited by laws that vary from country to
country. Check the laws in your local region before using this product for
surveillance purposes.
Electromagnetic Compatibility (EMC)
If use of this equipment causes harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures: Re-orient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect the equipment to an
outlet on a different circuit to the receiver. Consult your dealer or an
experienced radio/TV technician for help. Shielded (STP) network cables must
be used with this unit to ensure compliance with EMC standards.
USA - This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause interference, in which case the user will be
required to correct the interference at his own expense.
Canada - This Class A digital apparatus complies with Canadian ICES-003.
Europe - This digital equipment fulfills the requirements for radiated
emission according to limit A of EN55022/1998, and the requirements for
immunity according to EN55024/1998 residential, commercial, and industry.
Warning! This is a Class A product. In a domestic environment this product
may cause radio interference, in which case the user may be required to take
adequate measures.
Japan - This is a class A product based on the standard of the Voluntary
Control Council for Interference by Information Technology Equipment (VCCI).
If this equipment is used in a domestic environment, radio disturbance may
arise. When such trouble occurs, the user may be required to take corrective
action.
Australia - This electronic device meets the requirements of the Radio
communications (Electromagnetic Compatibility) Standard 1998 AS/NZS 3548.
Warning! This
is a Class A product. In a domestic environment this product
may cause radio interference, in which case the user may be required to take
adequate measures.
Liability
Every care has been taken in the preparation of this manual. Please inform
your local Axis office of any inaccuracies or omissions. Axis Communications
AB cannot be held responsible for any technical or typographical errors and
reserves the right to make changes to the product and manuals without prior
notice. Axis Communications AB makes no warranty of any kind with regard
to the material contained within this document, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose.
Axis Communications AB shall not be liable nor responsible for incidental or
consequential damages in connection with the furnishing, performance or use
of this material.
Trademark Acknowledgments
Ethernet, Internet Explorer, Linux, Microsoft, Mozilla, OS/2, UNIX, Wfine,
Windows, WWW are registered trademarks of the respective holders. Java and
all Java-based trademarks and logos are trademarks or registered trademarks
of Sun Microsystems, Inc. in the United States and other countries. Axis
Communications AB is independent of Sun Microsystems Inc. UPnP
TM
is a
certification mark of the UPnP
TM
Implementers Corporation. Bonjour is a
trademark of Apple Computer Inc.
Support
Should you require any technical assistance, please contact your Axis reseller.
If your questions cannot be answered immediately, your reseller will forward
your queries through the appropriate channels to ensure a rapid response. If
you are connected to the Internet, you can:
• download user documentation and firmware updates
• find answers to resolved problems in the FAQ database. Search by prod
uct,
category, or phrases
• report problems to Axis support by logging in to your private support area
Safety Notice - Battery Replacement
The AXIS 214 PTZ uses a 3.0V CR2032 Lithium battery as the power supply
for its internal real-time clock (RTC). Under normal conditions this battery will
last for a minimum of 5 years. Low battery power affects the operation of the
RTC, causing it to reset at every power-up. A log message will appear when the
battery needs replacing. The battery should not be replaced unless required!
If the battery does need replacing, please
observe the following:
• Danger of Explosion if battery is incorrectly replaced
• Replace only with the same or equivalent battery, as recommended by the
manufact
urer.
• Dispose of used batteries according to the manufacturer's instructions.
Visit Axis Support at www.axis.com/techsup/
RoHS
This product complies with both the European RoHS directive,
2002/95/EC, and the Chinese RoHS regulation
s, ACPEIP.
WEEE Directive
The European Union has enacted a Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE Directive). This directive
is applicable in the European Union member states.
The WEEE marking on this product (see right) or its documentation
i
ndicates that the product must not be disposed of together with household
waste. To prevent possible harm to human health and/or the environment, the
product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product
correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
Business users should contact the product suppl
ier for information on how to
dispose of this product correctly. This product should not be mixed with other
commercial waste.
AXIS 214 PTZ User’s Manual
Revision 3.1
Part No: 37546
November 2009
Copyright© Axis Communications AB, 2006-2009
