AXIS 214 PTZ
Network - UPnP™
The AXIS 214 PTZ includes support for UPnP™ in Windows Me and Windows XP. Enabled by default.
Note:
UPnP™ must be installed on your workstation. To do this, open the Control Panel from the Start Menu and select Add/Remove
Programs. Select Add/Remove Windows Components and open the Networking Services section. Click Details and then select
UPnP as the service to add.
Network - RTP / MPEG-4
These settings are for the IP addresses, port numbers, and Time-To-Live values to use for media streams in
the MPEG-4 format. Only certain IP addresses and port numbers should be used for these streams. For more
information, please see the online help.
Network - Bonjour
Your Axis network camera includes support for Bonjour. When enabled, the camera is automatically
detected by operating systems and clients that support this protocol.
Ports & Devices - I/O Ports
The pinout, interface support and the control and monitoring functions are described in the section
Connections, on page
39.
Maintenance
• Restart - The unit is restarted without changing any of the settings. Use this method if the unit is not
behaving as expected.
• Restore - The
unit is restarted and most current settings are reset to factory default values. The settings
that will not be reset are as follows:
• the boot protocol (DHCP or static)
• the static IP address
• the default router
•the subnet mask
• the system time.
• De
fault - The Factory default button should be used with caution. Pressing this button will reset all of
the AXIS 214 PTZ's settings to the factory default values (including the IP address).
Upgrade Server -
See Updating the Firmware, on page 40.
Backup - click the Backup button to take a backup of all of the parame
ters, and any user-defined scripts. If
necessary, it is then possible to return to the previous settings if the settings are changed and there is
unexpected behavior.
Note:
The root password will also be reset to the password saved in the backup file.
Restore - click the Browse button to locate the saved backup file (see above) and then click the Restore
button. The settings will be restored to the previous configuration.
Note:
Backup and Restore can only be used on the same unit running the same firmware. This feature is not intended for multi-unit
configuration or for firmware upgrades.
