Staple Position

ATU401S

• When two-sided printing is selected, adjust the staple position to the binding direction.

• If you are punching at the same time, specify the same side.

Staple Capacity (Booklet Finisher SR3000)

Paper Size Staple Capacity

A3 , B4 JIS , 11×17 , 8

×14 , 8×13

, 8

×13 , 8

×13 , 8K

A4 , B5 JIS , 8

×11 , 7

×10

, 16K

Booklet Staple:

A3 , B4 JIS , A4 , B5 JIS , 11×17 ,

×14 , 8

×11

3. Other Print Operations

132
