• If you are using a proxy server, change the Web browser settings. Contact your administrator for

information about the settings.

• If you click your browser's back button but the previous page does not appear, click the browser's

refresh button and try again.

• Printer information is not automatically updated. To perform an update, click [Refresh] in the display

area.

• We recommend using Web Image Monitor in the same network.

• You cannot access to the printer from outside the firewall.

• When using the printer under DHCP, the IPv4 address may be automatically changed by the DHCP

server settings. Enable DDNS setting on the printer, and then connect using the printer's host name.

Alternatively, set a static IPv4 address to the DHCP server.

• If the HTTP port is disabled, connection to the printer using the printer's URL cannot be established.

SSL setting must be enabled on this printer. For details, consult your administrator.

• When using the SSL encryption protocol, enter "https://(printer's address)/". Internet Explorer must

be installed on your computer. Use the most recent available version. We recommend Internet Explorer

6.0 or later.

• When you are using Firefox, fonts and colors may be different, or tables may be out of shape.

Displaying Top Page

This section explains the Top Page and how to display Web Image Monitor.

1. Start your Web browser.

2. Enter "http://(printer's address)/" in the address bar of a Web browser.

Top Page of Web Image Monitor appears.

If the printer's host name has been registered on the DNS or WINS server, you can enter it.

When setting SSL, a protocol for encrypted communication, under environment which server authen-

tification is issued , enter "https://(printer's address)/".

Every Web Image Monitor page is divided into the following areas:
