• mm

• inch

• Default:

• : mm

• : inch

Panel Key Sound

You can select whether or not to sound the beeper when the control panel is pressed.

• On

• Off

• Default: Off

Warm-up Beeper

You can select whether or not to sound the beeper when the printer has completed a warm-up process.

• On

• Off

• Default: On

Display Contrast

You can specify the density of the display.

Key Repeat

You can specify whether or not to scroll the display panel when the [ ] or [ ] key is held down. When

you enable this setting, specify the scroll speed. (If repeat time is set to "Long", scroll speed becomes

slow.)

• Do not Repeat

• Normal

• Repeat Time: Medium

• Repeat Time: Long

• Default: Off

Maintenance Menu

167
