Sub Paper Size
Specify whether or not to use paper of the alternate size automatically, if paper of the specified size
is not loaded. When this setting is set to off, the printer uses paper of any size loaded in the specified
tray.
• Auto
• Off
• Default: Off
Default Printer Lang.
Select the printer language to use when the printer fails to detect the printer language.
• PCL
• PS
• PDF
• Default: PCL
Energy Saver 1
Select whether or not to switch to Energy Saver 1 mode.
• On
• Off
• Default: Off
• When set to on, the printer switches to Energy Saver 1 mode after printing is complete. Electric
power consumption is greater than in Energy Saver 2 mode, but the printer returns to Ready
mode in about 10 seconds.
Energy Saver 2
In Energy Saver mode, electric power consumption is reduced.
Energy Saver On/Off
Select whether or not to switch to Energy Saver 2 mode.
• On
• Off
• Default: On
• When the printer switches to Energy Saver 2 mode, the Power indicator is unlit, but the
Online indicator remains lit.
5. Making Printer Settings Using the Control Panel
176
5
