Notify by Email

Specify whether or not to send an error message to a preset e-mail address when an error occurs in

the printer.

• Off

• On

• After changing the setting, turn off the power of the printer briefly, and then turn it on again.

• Default: On

• For information, see Web Image Monitor Help.

5. Making Printer Settings Using the Control Panel

178
